Mercedes-Benz E-Class Tire and Wheel Sizes: All Generations

BySerge Barrett

The Mercedes-Benz E-Class has been one of the most important luxury mid-size sedans in automotive history, spanning multiple generations since the early 1990s. Each generation introduced new wheel and tire size options to match evolving performance, comfort, and aesthetic standards. Understanding the correct tire and wheel specifications for your specific E-Class generation and trim is essential for maintaining ride quality, safety, handling characteristics, and preserving the vehicle’s TPMS calibration. This guide covers every generation of the E-Class with complete OEM tire and rim specifications.

W124 E-Class (1993–1995)

The W124 was the first Mercedes model to officially carry the ‘E-Class’ badge after the 1993 facelift. It used relatively conservative tire sizes typical of the early 1990s.

  • E200, E220, E280 – 195/65 R15 on 6.5J x 15 steel or alloy wheels
  • E320 – 205/60 R15 on 7J x 15 alloy wheels
  • E500 – 225/55 R16 on 7.5J x 16 alloy wheels
  • Bolt pattern: 5×112, center bore: 66.6 mm
  • Wheel offset (ET): ET37 for most variants

W210 E-Class (1995–2002)

The W210 introduced a wider range of engine options and trim levels, reflected in more varied wheel and tire specifications.

  • E200, E230, E240 – 195/65 R15 on 6.5J x 15
  • E280, E320 – 205/60 R15 or 205/55 R16 on 7J x 16
  • E430, E55 AMG – 225/45 R17 on 8J x 17
  • E55 AMG (later) – 245/40 R17 rear, 225/45 R17 front (staggered setup)
  • Bolt pattern: 5×112, center bore: 66.6 mm, ET: ET37–ET46

W211 E-Class (2002–2009)

The W211 significantly expanded the available wheel sizes, with AMG and Avantgarde packages offering larger diameter wheels as standard or optional equipment.

  • E200 CDI, E220 CDI – 205/55 R16 on 7J x 16
  • E200 Kompressor, E240 – 205/55 R16 or 225/50 R16 on 7.5J x 16
  • E280, E320, E350 – 225/50 R17 on 8J x 17
  • E500, E55 AMG – 245/40 R18 front / 265/35 R18 rear on 8.5J x 18 / 9.5J x 18
  • E63 AMG – 255/35 R19 front / 285/30 R19 rear on 9J x 19 / 10J x 19
  • Bolt pattern: 5×112, center bore: 66.6 mm, ET: ET46–ET52

W212 E-Class (2009–2016)

The W212 generation brought a wider body and more aggressive stance, enabling larger standard wheel sizes across all trim lines.

  • E200 CDI, E220 CDI (Elegance) – 205/60 R16 on 7J x 16
  • E250 CGI, E350 (Avantgarde) – 225/50 R17 on 7.5J x 17
  • E350 CDI, E400 (AMG Sport) – 245/40 R18 on 8.5J x 18
  • E500, E550 – 245/40 R18 front / 265/35 R18 rear on 8.5J x 18 / 9.5J x 18
  • E63 AMG (W212) – 255/35 R19 front / 285/30 R19 rear on 9J x 19 / 10.5J x 19
  • E63 AMG S 4MATIC – 265/35 R19 all around on 9.5J x 19
  • Bolt pattern: 5×112, center bore: 66.6 mm, ET: ET43–ET57

W213 E-Class (2016–2023)

The W213 is the most recent long-running generation, offering a broad spectrum of wheel and tire configurations depending on equipment level and engine grade.

  • E200, E220d (base) – 205/60 R16 on 7J x 16
  • E200, E220d (Avantgarde) – 225/55 R17 on 7.5J x 17
  • E300, E350d (AMG Line) – 245/45 R18 on 8J x 18
  • E400d, E450 (AMG Line+) – 255/35 R19 on 8.5J x 19
  • E43 AMG – 255/35 R19 front / 285/30 R19 rear on 8.5J x 19 / 9.5J x 19
  • E53 AMG – 255/35 R19 front / 285/30 R19 rear, optional 265/30 R20 front / 295/25 R20 rear
  • E63 AMG / E63 S AMG – 265/35 R20 front / 295/30 R20 rear on 9.5J x 20 / 10.5J x 20
  • Bolt pattern: 5×112, center bore: 66.6 mm, ET: ET46–ET57

W214 E-Class (2024–Present)

The latest generation W214 continues the tradition of offering a wide spread of wheel sizes with an emphasis on EV-optimized low-rolling-resistance options for hybrid variants.

  • E200 / E220d (standard) – 225/55 R17 on 7.5J x 17
  • E300 / E300e (Avantgarde) – 245/45 R18 on 8J x 18
  • E350e / E400d (AMG Line) – 255/40 R19 on 8.5J x 19
  • E53 AMG – 265/35 R20 front / 295/30 R20 rear on 9.5J x 20 / 10.5J x 20
  • Bolt pattern: 5×112, center bore: 66.6 mm, ET: ET46–ET57

Important Notes on Fitment and Replacements

  • All E-Class generations share the 5×112 bolt pattern — a Mercedes-Benz standard
  • Center bore is consistently 66.6 mm; always use hub-centric rings when fitting aftermarket wheels
  • Wheel offset (ET) varies: fitting wheels outside the OEM ET range can cause suspension wear and handling issues
  • TPMS sensors are standard from W211 facelift (2006+) onwards; replacement tires must be compatible with the sensor frequency (433 MHz on European models)
  • Run-flat tires (MOExtended or RFT) are factory-fitted on many W212 and W213 variants — do not replace with standard tires unless a spare wheel is added
  • Always verify the tire placard located on the driver’s door jamb for the exact recommended pressures and sizes for your specific build
  • AMG models use staggered setups — front and rear tires are not interchangeable
  • Winter tire minimum recommended size for W213: 225/55 R16 or larger on 7J x 16 steel wheels
